2.0 Screen-Printed Carbon Electrode (OGC-SPE-2.0)
OVERVIEW
OG Carbon 2.0 electrodes are disposable screen-printed carbon electrodes designed to provide good reproducibility. Each sensor contains carbon (graphite) working and counter electrodes and a silver/silver chloride reference electrode printed on a flexible PET support. The electrodes are suitable for biosensor research, quality-control systems and electrochemistry teaching.
Item No: OGC-SPE-2.0
Brand: OG Carbon
Country of origin: Not specified by the manufacturer
KEY FEATURES
Disposable screen-printed carbon electrodes with good reproducibility
Carbon (graphite) working and counter electrodes
Silver/silver chloride reference electrode
4 mm working-electrode diameter
Flexible white PET support
Compatible with a range of potentiostats and connectors
APPLICATIONS
Biosensor research and development
Electrochemical quality-control systems
Teaching of electrochemistry
Electrolysis
Modification with biomolecules
Formation of aryl layers using diazonium chemistry or similar methods
Detection of naphthol, dopamine, metals, para-aminophenol, metal complexes and other redox-active species
TECHNICAL SPECIFICATIONS
Specification | Details |
Sensor type | Screen-printed electrode |
Electrode system | Working, reference and counter electrodes |
Number of working electrodes | 1 |
Working-electrode material | Carbon (graphite) |
Working-electrode surface modification | Blank |
Working-electrode diameter | 4 mm |
Working-electrode geometric area | 12.57 mm² |
Counter-electrode material | Carbon (graphite) |
Reference-electrode material | Silver/silver chloride |
Reference and counter electrodes | Separate |
Support material | Flexible white PET |
Electrode dimensions | 10 mm × 33 mm × 0.25 mm |
Sensor connector | 3-pin SPE port |
Supply format | Easily cuttable strip of 25 electrodes |
