CR2032 Coin Cell Case, 304 Stainless Steel (TOB-2032-304SS)
OVERVIEW
A 304 stainless steel case set for assembling CR2032 coin cells. The case is specified with a PP gasket. Each set contains a cathode case and an anode case; spacers and wave springs are purchased separately.
Item No: TOB-2032-304SS
Brand: TOB New Energy
Country of origin: China
KEY FEATURES
304 stainless steel CR2032 case
PP gasket
20 mm diameter and 3.2 mm thickness
Cathode and anode cases supplied as a pair
Packed 100 case sets per bag
Suitable for use with the TOB-MR-120 sealing machine
APPLICATIONS
CR2032 coin-cell assembly
Sealing CR2032 cases with the TOB-MR-120
TECHNICAL SPECIFICATIONS
Specification | Details |
Model | CR2032 |
Case material | 304 stainless steel |
Gasket | PP |
Diameter | 20 mm |
Thickness | 3.2 mm |
Case-set contents | Cathode case and anode case |
Packing | 100 case sets per bag |
Spacer and wave spring | Purchased separately |
